| Scope of application: | Suitable for bus lanes, sidewalks, non motorized vehicle lanes, tunnels, highway speed bumps, overpasses, bus bays, long downhill slopes, sharp turns, toll station passages, and emergency stop zones on highways |
| Coating characteristics: | Paint curing agent has fast curing time, easy construction operation, and low odor |
| Excellent water resistance and good flexibility |
| Excellent chemical corrosion resistance |
| Good temperature resistance and extremely high slip resistance |
| Excellent interlayer adhesion, high bonding strength with concrete base surface |
| TECHNICAL INDEX | Drying time - surface drying: ≤ 4H |
| Drying time - practical: ≤ 6H |
| Pencil hardness: ≥ 2H |
| Wear resistance (750g/500r): ≤ 0.02g |
| Adhesion (grid method): Level 1 |
| Climate aging resistance (no foaming, no yellowing, no cracking after 800 hours): qualified |
| Resistant to 3% saline solution: no significant change for 7 days |
| Water resistance: No significant change after 7 days |
| Resistant to 20% sodium oxide gas: no significant change after 7 days |
| Resistant to gasoline 120 #: No significant change after 7 days |
| Construction procedures | construction method | Main materials - auxiliary materials | Reference amount |
| Plain ground | Color coated polymer road anti slip adhesive layer with trowel coating |
| 1-2 12-16 mesh) |
| undercoat | Solvent free epoxy resin coating for quartz stone repair, after curing, use sandpaper to polish and level, and clean the ground | DS-705 | About 2-2.5kg/m2 |
| Seal the concrete pavement with a special primer, and apply colored primer after the primer is completely dry | DS-400 | 0.5-0.75kg/m²左右 |
| Ceramic particle layer | Sprinkle colored wear-resistant aggregate on the surface of the colored base adhesive | DS-400- Quartz sand | 2-2.5kg/m²
|
| top coat | Evenly sprinkle the particles and completely cover the base adhesive. After 2-3 hours, clean the excess particles on the surface | DS-143 | 3-5kg/m2 |
|
| Construction procedures | Coating thickness: generally 1mm-3mm. If it exceeds 2mm, it needs to be sandblasted |
| Personnel can only enter after 24 hours of construction completion, and heavy pressure can only be applied after 72 hours. (Based on 25 * C, the low-temperature opening time needs to be moderately extended) |
